Course Contents

History of TOFD Development, TOFD Advantages and Limitations, Principles of TOFD, Principles of TOFD, Depth Calculation, Time Calculation, PCS Calculation, Types of TOFD Scan, Equipment Used In TOFD, Digitalization Principles, Equipment Requirements, TOFD Depth, Ring-Time Issues And Errors, Interpretation and Evaluation, Applications

Course Duration

14 Days

Course Objectives

• To explain the theoretical background of the techniques & the TOFD machine characteristics
• To calibrate TOFD equipment (velocity, Wedge delay, Sensitivity, Encoder)
• To Scan the plates and acquire the data
• To locate and evaluate defects using TOFD
• To select the correct type of probe/ machine parameters to examine welded butt joints in steel plate
• To report on the location and size of defects in typical welded butt joints
• To interpret code requirements
• To meet the syllabus requirements for ISO 9712 / ASNT-SNT-TC-1A Level 2

Certification / Awarding Body

ISO 9712 / ASNT-SNT-TC-1A

Entry Requirements (For Examination)

• The minimum required duration of training, which includes both theoretical and practical elements, is: Level 2 - 120 hours
• The minimum duration for experience prior to or following success in the qualification examination is : Level 2 - 12 Months
